2-2 ES User’s Guide
Getting Started
Introduction
Introduction
The HP 8712ES and HP 8714ES are easy-to-use, fully integrated RF
component test systems. Each instrument includes a synthesized source,
a wide dynamic range receiver, and a built-in test set. Controls are
grouped by functional block, and settings are displayed on the
instrument screen. This section familiarizes new users with the layout of
the front panel and the process of entering measurement parameters
into the analyzer.
Figure 2-1 Network Analyzer Front Panel Features
