HP 9000 Series Instruction Manual

Appendix B 101
Hardware Reference Information
Connector Information
Available HP Cables:
• HP 92268A - 4 meter with attached 8-pin connectors.
• HP92268B - 8-meter with attached 8-pin connectors.
• HP 92268C - 16-meter with attached 8-pin connectors.
• HP 92268D - 32-meter with attached 8-pin connectors.
• HP 92268N- 300-meter (no connectors supplied).
Cable Lengths:
The maximum length of the cable from the hub to each node for
100Base-TX is 100 meters. The cable must be category 5 UTP for
100Base-TX operation. For additional information on cable lengths and
number of nodes supported by 10/100Base-TX, refer to the IEEE 802.3u
Specification and Fast Ethernet, Dawn of a New Network by Howard W.
Johnson(published 1996 by PrenticeHall PTR, Upper Saddle River, New
Jersey 07458. Phone 800-382-3419. The ISBN number is 0-13-352643-7).
Table B-2 IEEE 802.3 Type 10Base-T Standard
Pins Signal
TX End Node
1
2
TX:1+
TX:1-
3
6
RX:1+
RX:1-
4
5
Unused
Unused
7
8
Unused
Unused
