102 AppendixB
Hardware Reference Information
HP-PB 10/100Base-TX Card
HP-PB 10/100Base-TX Card
Specifications.
Physical
Electrical
Environmental
Cable Interfaces
• The 10-Mbit/s twisted-pair port is compatible with IEEE 802.3u-1995
Type 10Base-T.
• The 100-Mbit/s twisted-pair port is compatible with IEEE
802.3u-1995 standard.
Communications Standards
• IEEE 802.3u-1995 Type 10Base-T (10Mbit/s).
• IEEE 802.3u-1995 standard (100-Mbit/s)
Dimensions: 231.14 mm by 30.48mm cm (9.1 in by 1.2 in)
Weight: .28 kg (10 oz)
DC Voltage: 4.75-5.25V
Typical Current: 1.8A
Maximum Current: 2.0A
Operating temperature:
5
o
C to 40
o
C
Storage temperature:
-40
o
C to +70
o
C
Relative humidity:
15% to 80% at 40
o
C non-condensing
