7. Select a radio button to indicate whether you will create a new XML Gateway
configuration or use an existing one.
Figure 26 XML Gateway
.
NOTE:
NetBackup gateway must always be present on the Master server. If you
are using Data Protector Manager-of-Managers (MoM) configuration, the
gateway must be present on the MoM server. See
“Manager-of-Managers configuration” on page 164 for more information.
If a user is using HP Data Protector as the backup manager and it runs in
a locale other than English, you must install the gateway on a system for
which the default encoding is same as the backup manager system.
8. If you are creating a new XML Gateway configuration, type the full network
name of the system the XML Gateway is running on. After clicking Next, you
are taken to Proxy Settings (if you selected Proxy Required) or to Save Backup
Manager.
9. Type details of the Proxy Server used to connect the Media Operations Server
and XML Gateway. Click Next.
10. Click Finish to save the Backup Manager and perform the initial configuration.
A window shows the configuration progress. When it completes, click OK.
What's next?
You have successfully configured a site and added a Backup Manager to it. To tune
the configuration further:
Configuring Media Operations74
