Speaker
Description Spare part number
Speaker 636925-001
The speaker is attached to the front of the chassis under the rotating drive cage.
1. Prepare the computer for disassembly (
Preparation for Disassembly on page 163).
2. Remove the access panel (
Access Panel on page 164).
3. Remove the front bezel (
Front Bezel on page 165).
4. Rotate the drive cage to its upright position.
5. Disconnect the speaker wire from the white system board labeled SPKR (1).
6. Remove the Torx screw that secures the speaker to the chassis (2).
7. Lift the speaker from the inside of the chassis to remove it (3).
Figure 8-34 Removing the speaker
To install the speaker, reverse the removal procedures.
196 Chapter 8 Removal and Replacement Procedures Small Form Factor (SFF) Chassis
