Description Spare part number
128-GB Solid-state Drive (SSD), SATA 2.0 665961-001
120-GB Solid-state Drive (SSD), SATA 2.0 661841-001
20-GB Solid-state Drive (SSD), SATA 683305-001
Optical drive
Blu-ray BD-RW SuperMulti DL Drive 656792-001
16X SATA DVD±RW drive 660408-001
16X SATA DVD-ROM drive 581599-001
Grommet, hard drive isolation, blue 594220-001
NOTE: 2.5-inch solid-state drives require an adapter for installation.
Misc boards
Description Spare part number
nVidia Quadro NVS310 PCIe x16 graphics card, 512 MB 680653-001
nVidia Quadro NVS300 PCIe x16 graphics card, 512 MB 632486-001
AMD Radeon HD7450 PCIe x16 graphics card, 1 GB 682411-001
AMD Radeon HD6350 PCIe x16 graphics card, 512 MB 637995-001
AMD FirePro 2270 PCIe x16 graphics card, 512-MB 637213-001
HP FireWire / IEEE 1394a PCIe x1 Card 637591-001
Intel PRO/1000CT2 NIC, includes bracket 635523-001
HP WLAN 802.11 g/n 1x2 PCIe NIC 538048-001
Sequential part number listing
Spare part
number
Description
370708-001 Foot kit
397117-001 Hard drive conversion bracket
463023-001 DMS-59 to dual VGA cable
484156-001 Adapter, DisplayPort to DVI
487562-001 DisplayPort cable
508987-001 Clamp lock, includes universal cable (plate not included)
537745-xx1 PS/2 basic keyboard for use in models without Windows 8
537746-xx1 USB basic keyboard for use in models without Windows 8
36 Chapter 4 Illustrated parts catalog
