HP Elite 8300 Series Small Form Factor User Manual

Port Cover
Description Spare part number
Port cover 646818-001
An optional rear port cover is available for the computer.
To install the port cover:
1. Thread the cables through the bottom hole on the port cover (1) and connect the cables to the
rear ports on the computer.
2. Insert the hooks on the port cover into the slots on the rear of the chassis, then slide the cover to
the right to secure it in place (2).
Figure 9-45 Installing a Port Cover
NOTE: For security purposes, you can install an optional cable lock to the chassis that locks the
port cover and secures the computer.
The port cover is secured in place by a retention lever just inside the port cover opening. To remove
the port cover, pull the lever back towards the port cover opening (1), then slide the cover to the left
and off the computer (2).
Port Cover 249

HP Elite 8300 Series Small Form Factor Specifications

General

Chipset	Intel Q77 Express
Processor	Intel Core i7-3770, Intel Core i5-3570, Intel Core i5-3470, Intel Core i3-3220
Memory	Up to 32 GB DDR3
Graphics	Integrated Intel HD Graphics
Optical Drive	DVD-ROM
Ports	USB, DisplayPort, VGA, serial, PS/2, audio in/out
Operating System	Windows 10, Windows 8, Windows 7, FreeDOS
Audio	Integrated high-definition audio
Network	Gigabit Ethernet
Power Supply	240W
Dimensions	33.8 x 37.9 x 10.0 cm
Weight	Approx. 7.6 kg
