Hard Drive
Description Spare part number
500 GB, 7200 rpm SATA hard drive, 2.5-inch, SED 696442-001
500-GB, 7200-rpm, 2.5-inch 686217-001
320 GB, 7200 rpm SATA hard drive, 2.5-inch, SED 634824-001
320 GB, 7200 rpm SATA hard drive, 2.5-inch 639135-001
256 GB Solid State Drive (SSD), self-encrypting (SED), 2.5-inch, SATA 6.0 680020-001
180 GB Solid State Drive (SSD), SATA 6.0 696622-001
160 GB Solid State Drive (SSD), SATA 3.0 646809-001
128 GB Solid State Drive (SSD), SATA 2.0 665961-001
120 GB Solid State Drive (SSD), SATA 2.0 661841-001
24 GB Solid State Drive (SSD), SATA 683306-001
NOTE: The Ultra-Slim Desktop supports only 2.5-inch Serial ATA (SATA) internal hard drives.
Before you remove the old hard drive, be sure to back up the data from the old hard drive so that you
can transfer the data to the new hard drive.
The 2.5-inch hard drive is enclosed in a carrier under the optical drive.
1. Prepare the computer for disassembly (
Preparation for Disassembly on page 207).
2. Remove the computer access panel (
Access Panel on page 208).
3. Remove the optical drive (
Removing the Optical Drive on page 219).
222 Chapter 9 Removal and Replacement Procedures Ultra-Slim Desktop (USDT) Chassis
