HP Elite 8300 Series Small Form Factor User Manual

Drives
Description Spare part number
Hard drive
500-GB, 7200-rpm, 2.5-inch, self-encrypting (SED) 696442-001
500-GB, 7200-rpm, 2.5-inch 686217-001
320-GB, 7200-rpm, 2.5-inch, self-encrypting (SED) 634824-001
320-GB, 7200-rpm, 2.5-inch 639135-001
256-GB Solid-state Drive (SSD), self-encrypting (SED), SATA 6.0 680020-001
180-GB Solid-state Drive (SSD), SATA 6.0 696622-001
160-GB Solid-state Drive (SSD), SATA 3.0 646809-001
128-GB Solid-state Drive (SSD), SATA 2.0 665961-001
120-GB Solid-state Drive (SSD), SATA 2.0 661841-001
32-GB Solid-state Drive (SSD), SATA 686616-001
24-GB Solid-state Drive (SSD), mSATA 683306-001
16-GB Solid-state Drive (SSD), SATA 688328-001
Optical drive
DVD-ROM drive 608394-001
DVD±RW and CD-RW Super Multi Double-Layer Combo Drive. This kit also includes the drive
bracket.
657958-001
Grommet, hard drive isolation, blue 594220-001
Misc boards
Description Spare part number
AMD Radeon HD 7650A (MXM) 687445-001
Intel Centrino Advanced-N 6205 (802.11a/b/g/n Wi-Fi wireless adapter) 652165-001
Sequential part number listing
Spare part
number
Description
484156-001 Adapter, DisplayPort to DVI
487562-001 DisplayPort cable
537745-xx1 PS/2 basic keyboard for use in models without Windows 8
537746-xx1 USB basic keyboard for use in models without Windows 8
537748-001 Mouse, PS2, optical, jack black
62 Chapter 4 Illustrated parts catalog
