Front Bezel
Description Spare part number
Front bezel for use in 8300 models 689380-001
Front bezel for use in 8380 models 689381-001
1. Prepare the computer for disassembly (Preparation for Disassembly on page 75).
2. Remove the computer access panel (
Access Panel on page 76).
3. Lift up the three tabs on the side of the bezel (1), then rotate the bezel off the chassis (2).
Figure 6-2 Removing the Front Bezel
To install the front bezel, reverse the removal procedure.
Front Bezel 77
