HP Elite 8300 Series Small Form Factor User Manual

Small Form Factor (SFF) chassis spare parts
Computer major components
Item Description Spare part number
(1) Front bezel 687950-001
Bezel blank (5.25-inch, optical drive; not illustrated) 570838-001
Bezel blank (3.5-inch; not illustrated) 583653-001
(2) Access panel 646815-001
(3) Power supply
240W, 90% efficient 613762-001
240W, standard 613763-001
(4) System board (includes replacement thermal material)
For use in models without Windows 8 657094-001
For use in models with Windows 8 Standard 657094-501
For use in models with Windows 8 Professional 657094-601
Memory modules (PC3-12800, 1666-MHz; not illustrated)
Small Form Factor (SFF) chassis spare parts 49

HP Elite 8300 Series Small Form Factor Specifications

General

Chipset	Intel Q77 Express
Processor	Intel Core i7-3770, Intel Core i5-3570, Intel Core i5-3470, Intel Core i3-3220
Memory	Up to 32 GB DDR3
Graphics	Integrated Intel HD Graphics
Optical Drive	DVD-ROM
Ports	USB, DisplayPort, VGA, serial, PS/2, audio in/out
Operating System	Windows 10, Windows 8, Windows 7, FreeDOS
Audio	Integrated high-definition audio
Network	Gigabit Ethernet
Power Supply	240W
Dimensions	33.8 x 37.9 x 10.0 cm
Weight	Approx. 7.6 kg
