HP Elite 8300 Series Small Form Factor User Manual

Spare part
number
Description
680020-001 256-GB Solid-state drive, self-encrypting (SED), SATA 6.0
680653-001 nVidia Quadro NVS310 PCIe x16 graphics card, 512 MB
682411-001 AMD Radeon HD7450 PCIe x16 graphics card, 1 GB
683305-001 20-GB Solid-state drive, SATA
687943-001 Intel Core i5 3470 (3.2-GHz, 6-MB L3 cache)
688162-001 Intel Core i5 3570 (3.4-GHz, 6-MB L3 cache)
688164-001 Intel Core i7 3770 (3.4-GHz, 8-MB L3 cache)
689375-001 Memory module, 8-GB, PC3 12800, CL11
689377-001 Front bezel for use in all countries and regions except for China
689378-001 Front bezel for use in China
691935-001 Intel Pentium G640 (2.8-GHz, 3-MB L3 cache)
691936-001 Intel Pentium G870 (3.1-GHz, 3-MB L3 cache)
696622-001 180-GB Solid-state drive (SSD), self-encrypting (SED), SATA 6.0
700510-xx1 Keyboard, washable, for use in models with Windows 8
701424-xx1 Keyboard, USB, black, for use in models with Windows 8
701426-xx1 Keyboard, wireless, for use in models with Windows 8
701427-xx1 Keyboard, smart card, for use in models with Windows 8
701428-xx1 Keyboard, PS/2, for use in models with Windows 8
701429-xx1 Keyboard, USB, silver/black, for use in models with Windows 8
48 Chapter 4 Illustrated parts catalog

HP Elite 8300 Series Small Form Factor Specifications

General

Chipset	Intel Q77 Express
Processor	Intel Core i7-3770, Intel Core i5-3570, Intel Core i5-3470, Intel Core i3-3220
Memory	Up to 32 GB DDR3
Graphics	Integrated Intel HD Graphics
Optical Drive	DVD-ROM
Ports	USB, DisplayPort, VGA, serial, PS/2, audio in/out
Operating System	Windows 10, Windows 8, Windows 7, FreeDOS
Audio	Integrated high-definition audio
Network	Gigabit Ethernet
Power Supply	240W
Dimensions	33.8 x 37.9 x 10.0 cm
Weight	Approx. 7.6 kg
