HP Elite Slice G2

WLAN module
Description
Intel Dual Band Wireless-AC 7265 NV
Intel Dual Band Wireless-AC 8260 + Bluetooth 4.0
Intel Dual Band Wireless-AC 8260 + Bluetooth 4.0 (non-vPro)
The WLAN module is secured with one Phillips screw and has two connected antennas.
To remove the WLAN module:
1. Remove the access panel (Access panel on page 21).
2. Remove the Base Module (Base Module on page 30).
3. Locate the WLAN module on the system board.
4. Disconnect both antenna cables from the WLAN module (1).
NOTE: You may need to use a small tool, such as tweezers, to disconnect and connect the antenna
cables.
5. Remove the Phillips screw (2) that secures the module to the system board.
32 Chapter 4 Removal and replacement procedures – HP Elite Slice Base Module
