Control panel message Description Recommended action
3. Replace chassis, rear chassis, or front
chassis fan.
903-Computer Cover Has Been Removed Since
Last System Startup
N/A
904-SATA Cabling Error One or more SATA devices are improperly
attached. For optimal performance, the SATA 0
and SATA 1 ports should be used for hard drives
before other ports.
Ensure SATA connectors are used in ascending
order. For one device, use SATA 0. For two
devices, use SATA 0 and SATA 1. For three
devices, use SATA 0, SATA 1, and SATA 2.
90B-Fan Failure The system has detected that a cooling fan is
not operating correctly.
1. Reseat fan.
2. Reseat fan cable.
3. Replace fan.
90D-System Temperature Thermal shutdown occurred. The system BIOS
has detected your machine was previously shut
down to avoid overheating. Overheating may
occur if the cooling vents are blocked or the
operating temperature exceeds the system
specications. The machine should return to
normal operation once the situation is resolved.
Make sure system has proper airow.
90E-Power Supply Fan Not detected Power supply fan is not connected or may have
malfunctioned.
1. Reseat power supply fan.
2. Reseat fan cable.
3. Replace power supply fan.
910–Filter Warning Airow lter is dirty. Replace the airow lter.
940–Unsupported Module Only HP modules are supported. Unrecognized
modules will not be enabled.
Only use supported HP modules.
Interpreting system validation diagnostic front panel LEDs and
audible codes
During the system validation phase that occurs at system startup, the BIOS validates the functionality of the
following subsystems and conditions:
AC adapter
System board power
Processor failure
BIOS corruption
Memory failure
Graphics failure
System board failure
BIOS authentication failure
If an error is detected, specic patterns of long and short blinks, accompanied by long and short beeps (where
applicable) are used to identify the error. These patterns will make up a two part code:
Interpreting system validation diagnostic front panel LEDs and audible codes 79
