2-28 Chapter2
HP ESA Status Registers
Using the Analyzer Status Registers
Figure 2-15
Bit Description
0, 1 Reserved. These bits are not used by the analyzer, but are for
future use with other HP products.
2 A 1 in this bit position indicates that a failure has occurred while
trying to align the tracking generator (TG).
3 A 1 in this bit position indicates that a failure has occurred while
trying to align the RF section.
4 A 1 in this bit position indicates that a failure has occurred while
trying to align the IF.
5 A 1 in this bit position indicates that a failure has occurred while
trying to align the local oscillator (LO).
6 A 1 in this bit position indicates that a failure has occurred while
trying to align the analog-to-digital converter (ADC).
7 A 1 in this bit position indicates that a failure has occurred while
trying to align the FM demodulation circuitry.
8 A 1 in this bit position indicates that a failure has occurred while
trying to align the quasi-peak detector.
9 Unused. These bits are always set to 0.
10 A 1 in this bit position indicates that a tracking peak needs to be
performed for the CAL OUTPUT (the tracking generator is in
operation).
11 A 1 in this bit position indicates that the alignment of the RF
section was skipped, perhaps due to an external 50 MHz signal
having been detected.
Bit Number
7
89101112131415
6
5
432
1
0
IF Align Failure
RF Align Failure
TG Align Failure
LO Align Failure
Reserved
Align Needed
Reserved
Align RF Needed
Tracking Peak Needed
Align RF Skipped
FM Demod Align Failure
Qpeak Align Failure
Unused
ADC Align Failure
Description
Always Zero (0)
Reserved
ck752a
Questionable Calibration Condition RegisterStatus
STATus:QUEStionable:CALibration:CONDition<num>
STATus:QUEStionable:CALibration:CONDition?
