Wireless configuration
Viewing wireless information
3-38
MHz = megahertz
ns = nanoseconds
Supported rates vary depending on the wireless operating mode.
Legacy rate traffic
Displays information for users connected via any 802.11 a/b/g mode. The size of the bar
indicates the amount of traffic sent or received at each rate.
9 26.00 28.90 54.00 60.00
10 39.00 43.30 81.00 90.00
11 52.00 57.80 108.00 120.00
12 78.00 86.70 162.00 180.00
13 104.00 115.6 216.00 240.00
14 117.00 130.00 243.00 270.00
15 130.00 144.40 270.00 300.00
16 130.00 144.40 270.00 300.00
17 130.00 144.40 270.00 300.00
18 130.00 144.40 270.00 300.00
19 130.00 144.40 270.00 300.00
20 130.00 144.40 270.00 300.00
21 130.00 144.40 270.00 300.00
22 130.00 144.40 270.00 300.00
23 195.00 216.60 405.00 600.00
MCS
Data rates in Mbps
Channel width / Guard interval
20 MHz/ 800 ns 20 MHz/ 400 ns 40 MHz/ 800 ns 40 MHz/ 400 ns
