HP MSR4080 User Manual

366
SamplerMode: 0 SamplerInt: 0
Active: 382.542 Bytes/Pkt: 1426
Table 79 Command output
Field Descri
p
tion
Active flow timeout Aging timer for active flows, in minutes.
Inactive flow timeout Aging timer for inactive flows, in seconds.
Max number of entries Maximum number of flows allowed in the cache.
IP active flow entries Number of active IP flows in the cache.
MPLS active flow entries Number of active MPLS flows in the cache.
L2 active flow entries Number of active Layer 2 flows in the cache.
IPL2 active flow entries Number of active Layer 2 and Layer 3 flows in the cache.
IP flow entries counted Number of IP flows that have been counted.
MPLS flow entries counted Number of MPLS flows that have been counted.
L2 flow entries counted Number of Layer 2 flows that have been counted.
IPL2 flow entries counted Number of Layer 2 and Layer 3 flows that have been counted.
Last statistics resetting time
Last time the reset ip netstream statistics command was executed. This
field displays Never if you have never executed this command.
IP packet size distribution (1103746
packets in total)
Distribution of IP packets by packet size, and the bracketed number is
the total number of IP packets.
The value is displayed in the proportion of the number of IP packets of
the specified sizes to the total number of IP packets, and the value is
displayed with 3 decimal places.
1-32 64 96 128 160 192 224
256 288
320 352 384 416 448 480 512
544 576
1024 1536 2048 2560 3072 3584
4096 4608
Range of IP packet length (excluding data link layer header) in bytes.
• For the values in the range of 1 to 576, the range increases in the
step of 32. For example, 1-32 shows the number of packets with
the size of 1 to 32 bytes. 64 shows the number of packets with the
size of 33 to 64 bytes.
• For the values greater than 1024, the range increases in the step of
512. For example, 1536 shows the number of packets with the size
of 1025 to 1536 bytes.
• Packets with the size of 577 to 1024 bytes are recorded in the
1024 entr y.
Protocol Total Flows Packets /sec
Flows/sec Packets/flow
Active(sec)/flow Idle(sec)/flow
Statistics of packets by protocol type:
• Protocol type.
• Total number of flows.
• Number of packets per second.
• Number of flows per second.
• Number of packets per flow.
• Active time (in seconds) of each flow.
• Inactive time (in seconds) of each flow.
