HP MSR4080 User Manual

390
Field Descri
p
tion
1-32 64 96 128 160 192 224 256
288
320 352 384 416 448 480 512 544
576
1024 1536 2048 2560 3072 3584 4096
4608 >4608
Range of IPv6 packet length (excluding data link layer header).
• For the values in the range of 1 to 576 bytes, the range
increases in the step of 32 bytes. For example, 1-32 shows the
number of packets with the size of 1 to 32 bytes. 64 shows the
number of packets with the size of 33 to 64 bytes.
• For the values greater than 1024 bytes, the range increases in
the step of 512 bytes. For example, 1536 shows the number of
packets with the size of 1025 to 1536 bytes.
• Packets with the size of 577 to 1024 bytes are recorded in the
1024 entr y.
Protocol Total Flows Packets/Sec
Flow/Sec Packets/flow
Active(sec)/ flow Idle(sec)/flow
Statistics of packets by protocol type:
• Protocol type.
• Total number of flows.
• Number of packets per second.
• Number of flows per second.
• Number of packets per flow.
• Active time (in seconds) of each flow.
• Inactive time (in seconds) of each flow.
Type DstIP(Port) SrcIP(Port) Pro TC
FlowLbl If(Direct) Pkts
Statistics of the active flows in the current cache:
• Flow type. Flows are classified into the following types:
{ IP flows.
{ Layer 2 flows with IPv6 protocol information (IPL2).
{ MPLS flows without IP options (MPLS).
{ MPLS flows with IP options (IP&MPLS).
• Destination IPv6 address (destination port).
• Source IPv6 address (source port).
• Protocol number.
• Traffic classification.
• Flow label.
• Interface name (direction).
• Number of packets.
ICMPv6 packets do not contain port number fields, so the type
and code fields are captured. The value for the destination port
represents these two fields:
• The highest 8 bits represent the type field.
• The lowest 8 bits represent the code field.
The value for the source port is set to 0 and does not indicate any
statistics.
DstMAC(VLAN) SrcMAC(VLAN)
Layer 2 information for the active flows in the current cache:
• Destination MAC address.
• Destination VLAN ID.
• Source MAC address.
• Source VLAN ID.
