34
Field Descri
p
tion
One way results
Unidirectional delay result.
This field is available only for the UDP jitter and voice operations.
Max SD delay Maximum delay from source to destination.
Max DS delay Maximum delay from destination to source.
Min SD delay Minimum delay from source to destination.
Min DS delay Minimum delay from destination to source.
Number of SD delay Number of delays from source to destination.
Number of DS delay Number of delays from destination to source.
Sum of SD delay Sum of delays from source to destination.
Sum of DS delay Sum of delays from destination to source.
Square-Sum of SD delay Square sum of delays from source to destination.
Square-Sum of DS delay Square sum of delays from destination to source.
SD lost packets Number of lost packets from the source to the destination.
DS lost packets Number of lost packets from the destination to the source.
Lost packets for unknown reason Number of lost packets for unknown reasons.
Voice scores
Voice parameters.
This field is available only for the voice operation.
Max MOS value Maximum MOS value.
Min MOS value Minimum MOS value.
Max ICPIF value Maximum ICPIF value.
Min ICPIF value Minimum ICPIF value.
Reaction statistics Statistics about the reaction entry in the counting interval.
Index ID of a reaction entry.
Checked Element Monitored element.
Threshold Type Threshold type.
Checked Num Number of targets that have been monitored for data collection.
Over-threshold Num Number of threshold violations.
Path
Serial number for the path in the path jitter operation.
This field is available only for the path jitter operation.
Hop IP
IP address of the hop.
This field is available only for the path jitter operation.
Path-jitter results
Path jitter operation results.
This field is available only for the path jitter operation.
Jitter number
Number of jitters.
This field is available only for the path jitter operation.
