HP ProLiant DL180 Gen9 - System Board Components

Component identification 14
2
Full-height, half-length
PCIe3 x8 (8, 4, 1)
3
FlexibleLOM
PCIe3 x8
System board components
Item
Description
1
FlexibleLOM sideband signal connector
2
System battery
3
Primary PCIe riser board connectors ("PCIe riser board slot
definitions" on page 12)
4
Dedicated iLO module connector
5
microSD card slot
6
SATA connector 5 (for M.2 SSD 2)
