HP ProLiant DL20 Gen10 Plus - Energy Pack Holder Spare Part

To Next Page

To Previous Page

Energy pack holder spare partEnergy pack holder spare part

Customer self repair: MandatoryMandatory

DescriptionDescription Spare part numberSpare part number

Energy pack holder P07881-001

For more information on the removal and replacement procedures, see Removing and replacing the energy pack holder .

Energy pack holder spare part 14
