HPEHPE NS204i-p NVMe OS Boot Device NS204i-p NVMe OS Boot Device components components

ItemItem DescriptionDescription

1 Drive bay 1

2 Drive bay 2

3 Thermal interface pad with removable liner

4 M.2 drive retaining latches

HPE NS204i-p NVMe OS Boot Device components 197
