Setup and Installation of the Packaged Cluster
Table 2-8: Two-port Shared Storage Module LEDs
Item LED Description
1 Power
2 SCSI host port A
3 SCSI host port B
HP ProLiant DL380 Generation 3 Packaged Cluster Setup and Installation Guide 2-11
