System Setup and Configuration for Red Hat Linux 7.3 Professional
Installing Management Agents for Servers for Linux
For instructions on installing and running Agents for Servers for Linux, refer to
the documentation located at
www.compaq.com/support/files/server/us/WebDoc/550/Linux.pdf
Configuring the Shared Storage
To configure the shared storage:
1. Power on one server and boot from the SmartStart 6.1 (or later) CD.
2. After booting with the SmartStart CD, click the Maintenance tab, then select and
run the Array Configuration Utility.
3. From the Array Configuration Utility Configuration screen, select the Smart
Array Cluster Controller to configure the shared storage hard drives. Refer to
the HP Array Configuration Utility User Guide on the documentation CD for
detailed information.
4. Reboot the server and log in.
5.
Format and mount the shared storage disks.
NOTE: No action is required on the second server at this time.
7-6 HP ProLiant DL380 Generation 3 Packaged Cluster Setup and Installation Guide
HP CONFIDENTIAL Codename: Sopwith Part Number: 252621-002 Last Saved On: 11/8/02 3:06 PM

HP ProLiant DL380 G3 with MSA1000 Specifications

General

Rack Height	2U
Hard Drive Interface	Ultra320 SCSI
Remote Management	Integrated Lights-Out (iLO)
Memory	PC2100 DDR SDRAM
Storage Controller	Smart Array 5i Plus
Network	Dual embedded NC7781 Gigabit NIC
Expansion Slots	6 PCI-X (64-bit/100 MHz)
Form Factor	Rackmount
MSA1000 Storage	External storage enclosure connected via SCSI
RAID Levels	0, 1, 5
Power Supply	Redundant Power Supply Optional
Drive Bays	6 hot-plug SCSI bays
Operating System Support	Windows Server, Linux
Processor	Intel Xeon (up to 3.6 GHz)
