Setup and Installation of the Packaged Cluster

Powering Down and Preparing for Transfer

1. Shut down the operating system and power off each server.

2. Power off the storage system.

3. Remove the power cords and return them to the original boxes.

4. Disconnect the VHDCI SCSI cables and the Ethernet crossover cable from the

servers.

5. Disconnect all other cables from the servers.

6. Replace the protective covers on the ends of the VHDCI SCSI cables.

7. Secure the VHDCI SCSI cables and the Ethernet crossover cable for transfer.

8. Repack the shipping components in their original configuration. Refer to the

exploded view diagram and pictures on the packaged cluster poster as a guideline

for repacking.

Configuration is complete. The packaged cluster is ready for transfer.

2-16 HP ProLiant DL380 Generation 3 Packaged Cluster Setup and Installation Guide

HP CONFIDENTIAL Codename: Sopwith Part Number: 252621-002 Last Saved On: 11/8/02 1:59 PM

Questions and Answers:

Need help?

Do you have a question about the HP ProLiant DL380 G3 with MSA1000 and is the answer not in the manual?

HP ProLiant DL380 G3 with MSA1000 Specifications

General

Rack Height	2U
Hard Drive Interface	Ultra320 SCSI
Remote Management	Integrated Lights-Out (iLO)
Memory	PC2100 DDR SDRAM
Storage Controller	Smart Array 5i Plus
Network	Dual embedded NC7781 Gigabit NIC
Expansion Slots	6 PCI-X (64-bit/100 MHz)
Form Factor	Rackmount
MSA1000 Storage	External storage enclosure connected via SCSI
RAID Levels	0, 1, 5
Power Supply	Redundant Power Supply Optional
Drive Bays	6 hot-plug SCSI bays
Operating System Support	Windows Server, Linux
Processor	Intel Xeon (up to 3.6 GHz)
