HP ProLiant DL380 G3 with MSA1000 User Manual

System Setup and Configuration for Novell NetWare 6
Creating Novell Storage Services Volumes and Pools
To create NSS volumes and pools:
1. Log in to ConsoleOne from one of the nodes and authenticate to the
appropriate tree.
2. Scroll down and highlight the cluster created earlier.
3. Select the Device Disk Management icon near the top of the screen.
4. Highlight a shared drive. (Be sure that it is not the drive containing DOS or
SYS.)
5. Select the Media tab and click NSS logical volumes.
6. Select New and enter a new logical volume name. Click Next.
7. Highlight the first external shared drive on the Smart Array Cluster Storage
system.
8. Select Allow volume quota to grow. Click Next.
9. Enter a Pool Name and click OK.
10. Assign a virtual IP address for the NSS volume. Click OK.
11. Select Finish.
NOTE: When prompted to continue creating the partition, click Yes.
12. Repeat steps 6 through 11 for all shared drives.
NOTE: At this point, all of the NSS Volumes that were created will be online in the
cluster.
Configuration is now complete.
6-6 HP ProLiant DL380 Generation 3 Packaged Cluster Setup and Installation Guide
HP CONFIDENTIAL Codename: Sopwith Part Number: 252621-002 Last Saved On: 11/8/02 3:00 PM

HP ProLiant DL380 G3 with MSA1000 Specifications

General

Rack Height	2U
Hard Drive Interface	Ultra320 SCSI
Remote Management	Integrated Lights-Out (iLO)
Memory	PC2100 DDR SDRAM
Storage Controller	Smart Array 5i Plus
Network	Dual embedded NC7781 Gigabit NIC
Expansion Slots	6 PCI-X (64-bit/100 MHz)
Form Factor	Rackmount
MSA1000 Storage	External storage enclosure connected via SCSI
RAID Levels	0, 1, 5
Power Supply	Redundant Power Supply Optional
Drive Bays	6 hot-plug SCSI bays
Operating System Support	Windows Server, Linux
Processor	Intel Xeon (up to 3.6 GHz)
