HP ProLiant DL380 G3 with MSA1000 User Manual

System Setup and Configuration for Novell NetWare 6
HP ProLiant DL380 Generation 3 Packaged Cluster Setup and Installation Guide 6-7
HP CONFIDENTIAL Codename: Sopwith Part Number: 252621-002 Last Saved On: 11/8/02 3:00 PM
Validating the Cluster Configuration
1. Log in to ConsoleOne from one of the nodes and authenticate to the
appropriate tree.
2. Scroll down and highlight the cluster created earlier.
3. From the title bar select View, Cluster State View.
4. Be sure that all cluster nodes and resources are online and running.
5. Double-click the first cluster volume resource.
6. Highlight the node name in the list of available nodes and click Migrate.
7. Be sure that the cluster volume resource migrates to the selected node.
8. Repeat steps 5 through 7 for all cluster volume resources.
IMPORTANT: If the packaged cluster is being transferred, return to “Setup in the
Configuration Fixture” in Chapter 2 or refer to the packaged cluster hardware installation and
configuration poster to complete the process.

HP ProLiant DL380 G3 with MSA1000 Specifications

General

Rack Height	2U
Hard Drive Interface	Ultra320 SCSI
Remote Management	Integrated Lights-Out (iLO)
Memory	PC2100 DDR SDRAM
Storage Controller	Smart Array 5i Plus
Network	Dual embedded NC7781 Gigabit NIC
Expansion Slots	6 PCI-X (64-bit/100 MHz)
Form Factor	Rackmount
MSA1000 Storage	External storage enclosure connected via SCSI
RAID Levels	0, 1, 5
Power Supply	Redundant Power Supply Optional
Drive Bays	6 hot-plug SCSI bays
Operating System Support	Windows Server, Linux
Processor	Intel Xeon (up to 3.6 GHz)
