Setup and Installation of the Packaged Cluster
Setup and Installation in a Rack
Perform the following procedures to set up the packaged cluster in a rack.
WARNING: To reduce the risk of personal injury or damage to the equipment,
at least two people are required to lift the components during installation or
removal.
Rack Planning Resources
The rack resource kit ships with Compaq or HP 7000-, 9000-, and 10,000-series
racks. For more information on the content of each resource, refer to the rack
Documentation CD.
Installing the Storage System into the Rack
The rack mounting hardware kit provides the required components for quick
deployment in Compaq branded, HP branded, and most square- and round-hole
third-party racks. The adjustable feature of the rack rails enables installation in racks
with depths of 69.90 to 73.81 cm (27.52 to 29.06 inches).
HP ProLiant DL380 Generation 3 Packaged Cluster Setup and Installation Guide 2-17
HP CONFIDENTIAL Codename: Sopwith Part Number: 252621-002 Last Saved On: 11/8/02 1:59 PM

HP ProLiant DL380 G3 with MSA1000 Specifications

General

Rack Height	2U
Hard Drive Interface	Ultra320 SCSI
Remote Management	Integrated Lights-Out (iLO)
Memory	PC2100 DDR SDRAM
Storage Controller	Smart Array 5i Plus
Network	Dual embedded NC7781 Gigabit NIC
Expansion Slots	6 PCI-X (64-bit/100 MHz)
Form Factor	Rackmount
MSA1000 Storage	External storage enclosure connected via SCSI
RAID Levels	0, 1, 5
Power Supply	Redundant Power Supply Optional
Drive Bays	6 hot-plug SCSI bays
Operating System Support	Windows Server, Linux
Processor	Intel Xeon (up to 3.6 GHz)
