System Setup and Configuration for Microsoft Windows 2000 Advanced Server
3-6 HP ProLiant DL380 Generation 3 Packaged Cluster Setup and Installation Guide
HP CONFIDENTIAL Codename: Sopwith Part Number: 252621-002 Last Saved On: 11/8/02 2:05 PM
4. Rerun the ProLiant Support Pack for Windows 2000 to ensure that the latest HP
drivers were not overwritten by the service pack. Reboot if prompted.
5. Power on the second server and repeat steps 2 through 4.
Validating the Cluster Configuration
To validate the cluster configuration, perform the following steps from either cluster
node:
1. Select Start, Programs, Administrative Tools, Cluster Administrator, and
connect to the cluster.
2. Right-click one group. Select Move Group.
3. Verify the group fails over to the other node and all resources come online.
4. Right-click the same group. Select Move Group.
5. Verify that the group fails back to the original node and all resources come
online.
6. Repeat steps 2 through 5 for each group.
Configuration is now complete.
IMPORTANT: If the packaged cluster is being transferred, return to “Setup in the
Configuration Fixture” in Chapter 2 or refer to the packaged cluster hardware installation and
configuration poster to complete the process.

HP ProLiant DL380 G3 with MSA1000 Specifications

General

Rack Height	2U
Hard Drive Interface	Ultra320 SCSI
Remote Management	Integrated Lights-Out (iLO)
Memory	PC2100 DDR SDRAM
Storage Controller	Smart Array 5i Plus
Network	Dual embedded NC7781 Gigabit NIC
Expansion Slots	6 PCI-X (64-bit/100 MHz)
Form Factor	Rackmount
MSA1000 Storage	External storage enclosure connected via SCSI
RAID Levels	0, 1, 5
Power Supply	Redundant Power Supply Optional
Drive Bays	6 hot-plug SCSI bays
Operating System Support	Windows Server, Linux
Processor	Intel Xeon (up to 3.6 GHz)
