Setup and Installation of the Packaged Cluster
3. Connect the peripheral devices such as the keyboard, mouse, and monitor. For
information on peripheral device connections, refer to “Component and LED
Identification” in this chapter.
WARNING: To reduce the risk of electric shock, fire, or damage to the
equipment, do not plug telephone or telecommunications connectors into
RJ-45 connectors.
IMPORTANT: If the Remote Insight Lights-Out Edition II (RILOE II) board is installed in
the server, be sure that you can attach the video cable to the video connector on the rear
of the RILOE II board. The standard video connector on the server rear panel is not used
when the RILOE II board is installed. For more information, refer to the HP Remote Insigh
Lights-Out Edition II User Guide on the Documentation CD.
NOTE: If you are using a KVM switchbox, refer to the switchbox documentation for
detailed instructions.
4. Connect the power cords to the servers and storage system.
5. Configure the packaged cluster. Install the required operating system and
software applications. Refer to the appropriate operating system chapter in this
guide for instructions on configuring and installing the operating system.
IMPORTANT: Go to “Powering Down and Preparing for Transfer” after the operating system
has been installed.
HP ProLiant DL380 Generation 3 Packaged Cluster Setup and Installation Guide 2-15
HP CONFIDENTIAL Codename: Sopwith Part Number: 252621-002 Last Saved On: 11/8/02 1:59 PM
