Setup and Installation of the Packaged Cluster
11. Use the shipping bracket to secure the system in the rack for shipping:
a. Loosen the thumbscrew on the shipping bracket.
b. Slide the shipping bracket forward until it engages the storage system
chassis.
1
2
c. Tighten the thumbscrew.
2-26 HP ProLiant DL380 Generation 3 Packaged Cluster Setup and Installation Guide
HP CONFIDENTIAL Codename: Sopwith Part Number: 252621-002 Last Saved On: 11/8/02 1:59 PM
