Setup and Installation of the Packaged Cluster

2-36 HP ProLiant DL380 Generation 3 Packaged Cluster Setup and Installation Guide

HP CONFIDENTIAL Codename: Sopwith Part Number: 252621-002 Last Saved On: 11/8/02 1:59 PM

7. Route the cables and secure to the cable management arm.

8. Connect the power cords to the AC power source.

WARNING: To reduce the risk of electric shock or damage to the

equipment:

• Do not disable the power cord grounding plug. The ground plug is an

important safety feature.

• Plug the power cord into a grounded (earthed) electric outlet that is

easily accessible at all times.

• Unplug the power cord from the power supply to disconnect power to

the equipment.

• Do not route the power cord where it can be walked on or pinched by

items placed against it. Pay particular attention to the plug, electric

outlet, and the point where the cord extends from the server.

9. Configure the packaged cluster. Install the required operating system and

software applications. Refer to the appropriate operating system chapter in this

guide for instructions on configuring and installing the operating system.

Questions and Answers:

Need help?

Do you have a question about the HP ProLiant DL380 G3 with MSA1000 and is the answer not in the manual?

HP ProLiant DL380 G3 with MSA1000 Specifications

General

Rack Height	2U
Hard Drive Interface	Ultra320 SCSI
Remote Management	Integrated Lights-Out (iLO)
Memory	PC2100 DDR SDRAM
Storage Controller	Smart Array 5i Plus
Network	Dual embedded NC7781 Gigabit NIC
Expansion Slots	6 PCI-X (64-bit/100 MHz)
Form Factor	Rackmount
MSA1000 Storage	External storage enclosure connected via SCSI
RAID Levels	0, 1, 5
Power Supply	Redundant Power Supply Optional
Drive Bays	6 hot-plug SCSI bays
Operating System Support	Windows Server, Linux
Processor	Intel Xeon (up to 3.6 GHz)
