Removal and replacement procedures 64
9.
Disconnect the power cable.
10. Loosen the thumbscrews, and then remove the backplane.
To replace the component, reverse the removal procedure.
Express Bay Bridge card
CAUTION: To prevent damage to electrical components, take the appropriate anti-static
precautions before beginning any system installation. Improper grounding can cause
electrostatic discharge.
To remove the component:
1. Power down the server (on page 26).
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
