HP ProLiant ML30 Gen10 Plus

To Next Page

To Previous Page

ItemItem DescriptionDescription

1 Media bay 1

2 Media bay 2

3 USB 3.2 Gen1 port

4 USB 2.0 port

5 8 SFF hot-plug drives

Media 1 supports a SATA optical drive, SAS LTO drive, or a USB RDX docking station.

Media 2 supports a SATA optical drive or a USB RDX docking station.

Front panel components 9
