Component identification 10
*Slots 1 and 2 are available only when an optional PCI-X extender board is installed.
Rear panel LEDs and buttons
Item Description Status
1 UID button/LED Blue = Activated
Flashing = System is being managed remotely.
Off = Deactivated
2 NIC/iLO 2 activity Green or flashing green = Activity exists.
Off = No activity exists.
3 NIC/iLO 2 link Green = Link exists.
Off = No link exists.
