Component identification 9
Rear panel components
Item Description
1 Dedicated iLO 2 management port (optional)
2 Serial connector
3 10/100/1000 NIC 2 connector
4
10/100/1000 NIC 1 connector/shared iLO 2
management port
5 Mouse connector
6 Power supply 1
7 Power supply blank
8 Slot 1 PCI-X*
9 Slot 2 PCI-X*
10 Slot 3 PCIe1 x8 (1)
11 Slot 4 PCIe2 x16 (16, 8, 4, 2, 1)
12 Slot 5 PCIe2 x8 (4, 2, 1)
13 Slot 6 PCIe2 x8 (4, 2, 1)
14 Video connector
15 USB connectors (2)
16 Keyboard connector
