Access Panel
Description Spare part number
Access panel 653026-001
1. Prepare the computer for disassembly (Preparation for Disassembly on page 41).
2. Slide the access panel handle toward the rear of the computer (1) then lift the access panel up
and off the computer (2).
Figure 7-1 Removing the Computer Access Panel
To install the computer cover, reverse the removal procedure.
42 Chapter 7 Removal and Replacement Procedures
