Speaker
Description Spare part number
Speaker 636925-001
1. Prepare the computer for disassembly (Preparation for Disassembly on page 41).
2. Remove the access panel (
Access Panel on page 42).
3. Remove the front bezel (
Front Bezel on page 43).
4. Rotate the drive cage to its upright position.
5. Disconnect the speaker wire from the system board connector labeled SPKR.
Figure 7-54 Removing the Speaker Cable
Speaker 89
