Page #64 background imageLoading...
Page #64 background image
Expansion Cards
Description Spare part number
Expansion cards
HP FireWire / IEEE 1394a PCIe x1 card 637591-001
PCIe to PCI riser – 24V 638943-001
PCIe to PCI riser – 24V 638944-001
Powered USB card – 12V 638945-001
2-port powered serial card 638947-001
Ports
eSATA port assembly, PCI card 645558-001
Serial port (COMB) card 638946-001
Printer port, PCI card 638817-001
Other boards/cards
Modem, LSI, v.92 490689-001
Intel PRO/1000CT NIC, includes bracket 635523-001
Introduction
The computer has the following expansion options:
There are two riser cards available from HP for this product. One has two PCI slots and the
other has two PCI Express x1 slots. Both cards have a slot designated for the Powered Serial
Port expansion card. You can purchase either card as a replacement from HP.
Full-height expansion cards can be installed into the riser card slots on the computer.
There are two riser cards available from HP for this product. One has two PCI slots and the
other has two PCI Express x1 slots. Both cards have a slot designated for the Powered Serial
Port expansion card.
CAUTION: The Powered Serial Port expansion card slot on the riser cards looks very similar to
a PCI Express x1 expansion card slot. Do not attempt to insert a PCI Express x1 expansion card
into the Powered Serial Port expansion card slot and do not attempt to insert a Powered Serial
Port expansion card into a PCI Express x1 expansion card slot
The computer system board has a PCI Express x1 expansion slot, a PCI Express x16 expansion
slot, and a riser card expansion slot. The riser card expansion slot is populated with a riser card
specifically designed for this product. You can install expansion cards into the PCI Express x1
and PCI Express x16 slots as needed.
NOTE: The PCI Express slots support only low profile cards.
You can install a PCI Express x1, x4, x8, or x16 expansion card in the PCI Express x16 slot.
54 Chapter 7 Removal and Replacement Procedures
