Removing a 3.5-inch Secondary Hard Drive from a Drive Bay
NOTE: Before you remove the old hard drive, be sure to back up the data from the old hard drive so
that you can transfer the data to the new hard drive.
The 3.5-inch secondary hard drive is located underneath the 5.25-inch optical drive. You must
remove the 5.25-inch optical drive before removing the 3.5-inch secondary hard drive.
1. Follow the procedure in
Removing a 5.25-inch Optical Drive from a Drive Bay on page 76 to
remove the optical drive and access the secondary hard drive.
CAUTION: Ensure that the computer is turned off and that the power cord is disconnected
from the electrical outlet before proceeding.
2. Disconnect the power cable and data cable from the back of the hard drive.
3. Press down on the green drive retainer button located on the left side of the drive to disengage
the drive from the drive cage (1). While pressing the drive retainer button, slide the drive back
until it stops, then lift it up and out of the drive cage (2).
Figure 7-41 Removing a Secondary Hard Drive
Drives 79
