Front Bezel
Description Spare part number
Front bezel 653025-001
1. Prepare the computer for disassembly (Preparation for Disassembly on page 41).
2. Remove the access panel (
Access Panel on page 42).
3. Lift up the three tabs on the side of the bezel (1), then rotate the bezel off the chassis (2).
Figure 7-2 Removing the Front Bezel (shown with optical drive installed)
To install the new front bezel, reverse the removal procedure.
Front Bezel 43
