HP rp5800 User Manual

Fan Duct
Description Spare part number
Fan duct 636921-001
1. Prepare the computer for disassembly (Preparation for Disassembly on page 41).
2. Remove the access panel
Access Panel on page 42).
3. Remove the cables routed in the arm that extends from the top of the fan duct.
Figure 7-48 Removing the Cables from the Fan Duct
84 Chapter 7 Removal and Replacement Procedures

HP rp5800 Specifications

General

Processor	Intel Core i3-2120 (3.3 GHz, 3 MB cache, 2 cores)
Memory	4 GB DDR3
Storage	500 GB SATA (7200 rpm)
Operating System	Windows 7 Professional (64-bit)
Ports	VGA, DisplayPort, serial, parallel, audio in/out, RJ-45
Power Supply	240W
