50°C configuration components
Description Spare part number
50°C thermal kit, includes:
● Heat sink, copper based
● Partition
● Radial fan, 70mm
●
Fan holder
●
Vented slot covers
●
Front bezel trim, no optical drive
649033-001
The following sections provide procedures for removing the components specific to the optional 50°C
thermal configuration of the rp5800. The 50°C configuration allows the computer to achieve 50°C
ambient thermals.
Requirements for 50°C configurations include:
●
No optical drive – special radial fan assembly installed in optical drive bay
●
Installation of special heat partition that creates two thermal chambers that keeps preheated
processor heat from entering the hard drive and power supply chamber. The partition also keeps
cool air in the hard drive/power supply chamber by preventing it from mixing into the processor
chamber.
●
Copper-based heat sink (in place of standard aluminum-based heat sink)
●
No expansion cards
●
Maximum 65W processor
●
Installation on vented expansion slot covers on rear
●
Front bezel without optical drive slot
●
No add-in cards
●
Maximum of one hard drive or solid-state drive
98 Chapter 7 Removal and Replacement Procedures
