b. Connect the USB cable to the cable connector on the accessory (1), and then connect the grounding
connector to the grounding strip on the accessory, if applicable (2).
NOTE: The connectors shown are for a proximity card reader. The cable connector for your
accessory might be slightly different, and might not include a ground connector.
ENWW Install an accessory into the hardware integration pocket 99
