4. Lift up on the separation pad component, release it from its housing, and set it aside.
TIP: This is easier to do if you lower the input tray.
CAUTION: Do not touch the pad itself with bare fingers, as oils from your fingers could impact
performance.
5. Slide the rear edge of the new separation pad component into its housing, ensuring that the spring below
the pad is not bent down.
ENWW Replace the separation pad 85
