Table 3-1 Computer major component descriptions and part numbers (continued)
Item Component Spare part number
System Board Repair Kit (not illustrated) N56255-888
(11) Heat sink (includes captive screws and replacement thermal material):
For use with system boards equipped with a graphics subsystem with discrete memory and an
Intel i-9 or Intel i-8 processor
N10927-001
For use with system boards equipped with a graphics subsystem with discrete memory and an
Intel i-7 or Intel i-6 processor
N51005-001
For use with system boards equipped with a graphics subsystem with UMA memory N10925-001
(12) Fan Kit (includes left and right fans, captive screws, and cables) N10924-001
(13a) Memory modules (2, SODIMM, DDR5-5600, 1.1 V, NECC):
32 GB N51121-001
16 GB N38627-001
8 GB N37792-002
Memory modules (2, SODIMM, DDR5-4800, 1.1 V, NECC):
32 GB N19982-001
16 GB M97596-002
8 GB M97595-002
(13b) Memory module shield (included in the Shield Kit, spare part number N10942-001)
(14) Battery (6 cell, 86 Whr, Li-ion) M82230-005
(15) Bottom speakers (included in the Speaker Kit, spare part number N51007-001; includes left and right top speakers, left
and right bottom speakers, cables, and 4 rubber isolators)
(16a) Solid-state drive:
4 TB, M.2 2280, PCIe-4×4, NVMe, dual-sided solid-state drive with TLC N06219-002
2 TB, M.2 2280, PCIe-4×4, NVMe solid-state drive with TLC M52027-002
1 TB, M.2 2280, PCIe-4×4, NVMe solid-state drive with TLC M16560-002
1 TB, M.2 2280, PCIe-4×4, NVMe, self-encrypting solid-state drive with TLC N23415-002
512 GB, M.2 2280, PCIe-4×4, NVMe solid-state drive with TLC M17436-002
512 GB, M.2 2280, PCIe-4×4, self-encrypting solid-state drive with TLC M52031-002
(16b) Solid-state drive shield (included in the Sheild Kit, spare part number N10942-001)
(17) Bottom cover (includes rubber feet) N51006-001
Display assembly subcomponents
To identify the display assembly subcomponents, use this illustration and table.
Display assembly subcomponents
25
