HP ZBOOK STUDIO 16 G10 User Manual

IMPORTANT: Removing a battery that is the sole power source for the computer can cause loss of
information. To prevent loss of information, save your work or shut down the computer through
Windows before you remove the battery.
Remove the battery:
1. Loosen the seven Phillips captive screws (1) that secure the battery to the computer.
2. Swing the rear edge of the battery (2) up and forward until it rests at an angle.
3. Remove the battery (3) by sliding it up and back at an angle.
To insert the battery, reverse the removal procedure.
Memory modules
To remove the memory modules, use this procedure and illustration.
Table 5-5
Memory module descriptions and part numbers
Description Spare part number
Memory modules (2, SODIMM, DDR5-5600, 1.1 V, NECC):
32 GB N51121-001
16 GB N38627-001
8 GB N37792-002
Memory modules (2, SODIMM, DDR5-4800, 1.1 V, NECC):
32 GB N19982-001
16 GB M97596-002
8 GB M97595-002
Memory module shield (included in the Shield Kit, spare part number N10942-001)
Before removing the memory modules, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 40).
2. Remove the bottom cover (see Bottom cover on page 40).
Memory modules
47

HP ZBOOK STUDIO 16 G10 Specifications

General

Operating System	Windows 11 Pro
Wireless	Wi-Fi 6E, Bluetooth 5.3
Webcam	5MP IR Camera
Audio	Bang & Olufsen, dual speakers
Keyboard	Backlit, spill-resistant
Processor	Intel Core i7 or i9 (13th Gen)
Graphics	NVIDIA RTX 2000 Ada Generation Laptop GPU
Display	16-inch, 2560 x 1600, IPS
RAM	Up to 64GB DDR5
Storage	Up to 2TB PCIe NVMe SSD
Weight	1.73 kg
Battery	86 Wh Li-ion polymer
Ports	2 x Thunderbolt 4, 1 x HDMI 2.1, 1 x headphone/microphone combo
Security	Fingerprint sensor, TPM 2.0
