HP ZBOOK STUDIO 16 G10 User Manual

3. Remove the solid-state drive (see Solid-state drive on page 42).
4. Remove the battery (see Battery on page 46).
5. Remove the fans (see Fans on page 49).
6. Remove the heat sink (see Heat sink on page 49).
7. Remove the system board (see System board on page 62).
Remove the touchpad cable:
1. Release the ZIF connector (1) the touchpad cable is connected to, and then disconnect the
touchpad cable from the transfer board.
2. Release the ZIF connector (2) the touchpad cable is connected to, and then disconnect the
touchpad cable from the touchpad.
3. Detach the touchpad cable (3) from the computer. The touchpad cable is attached to the computer
with double-sided adhesive.
4. Remove the touchpad cable.
To install the touchpad cable, reverse the removal procedure.
Touchpad
To remove the touchpad, use this procedure and illustration.
Table 5-12
Touchpad description and part number
Description Spare part number
Touchpad
NOTE: The touchpad spare part kit does not include the touchpad cable. The touchpad cable is
available using spare part number N10935-001.
N10923-001
Before removing the touchpad, follow these steps:
72
Chapter 5 Removal and replacement procedures for authorized service provider parts

HP ZBOOK STUDIO 16 G10 Specifications

General

Operating System	Windows 11 Pro
Wireless	Wi-Fi 6E, Bluetooth 5.3
Webcam	5MP IR Camera
Audio	Bang & Olufsen, dual speakers
Keyboard	Backlit, spill-resistant
Processor	Intel Core i7 or i9 (13th Gen)
Graphics	NVIDIA RTX 2000 Ada Generation Laptop GPU
Display	16-inch, 2560 x 1600, IPS
RAM	Up to 64GB DDR5
Storage	Up to 2TB PCIe NVMe SSD
Weight	1.73 kg
Battery	86 Wh Li-ion polymer
Ports	2 x Thunderbolt 4, 1 x HDMI 2.1, 1 x headphone/microphone combo
Security	Fingerprint sensor, TPM 2.0
