HPE Aruba Networking CX 6200 Series User Manual

Switch LEDs Function State Meaning
UID LED User-configurable LED Off User defined the
located LED : OFF
On/Flash Blue (for
30 min)
User defined the
locator LED:
On/Flash
Global Status
Indicator LED
Overall status of the product Flash - Green Self-test in progress
during UBOOT and
SVOS
On - Green Successfully booted
AOS-CX
Flash - Amber Recoverable faults
(e.g. fans, PSU fault)
On - Amber Critical faults (e.g.
exceed
temperature limit)
OOBM Status
Indicator LED
Status of OOBM Link connectivity Off OOBM port is not
connected, no link
established
Half Bright - Green OOBM port is
enabled and
established link
with partner
On - Green Experiencing high
bandwidth
utilization
Activity Flicker -
Green
% of the time that
the LED light up is
roughly
proportional to the
% of full bandwidth
utilization of the
port
* Press the Mode Select button to switch between User(default), PoE, Spd, or Stk Mode.
Switch LEDs Function State/Mode Meaning
Fan health LED Status of fan On - Green Normal
Slow flash - Amber Fan fault
UID LED User-configurable LED Off User define the
locator LED : OFF
On/Flash (30 min) -
blue
User define the
locator LED:
On/Flash
Table 22: Rear Panel LED Behavior
HPE Aruba Networking CX 6200F/M Switch Series Installation and Getting Started Guide |
55
