Chapter 7
Cabling and technology information
Cabling and technology information
This section includes switch connector information and network cable information for cables used with
the Aruba switches.
Incorrectly wired cabling is a common cause of problems for LAN communications. Aruba recommends that you
work with a qualified LAN cable installer for assistance with your cabling requirements.
Cabling specifications
J9281D Aruba 10G SFP+ to SFP+ 1m Direct Attach Copper Cable
J9283D Aruba 10G SFP+ to SFP+ 3m Direct Attach Copper Cable
Table 25: Supported Cables
J4858D Aruba 1G SFP LC SX 500m MMF Transceiver
J4859D Aruba 1G SFP LC LX 10km SMF Transceiver
J4860D Aruba 1G SFP LC LH 70km SMF Transceiver
J8177D Aruba 1G SFP RJ45 T 100m Cat5e Transceiver
J9150D Aruba 10G SFP+ LC SR 300m MMF Transceiver
J9151E Aruba 10G SFP+ LC LR 10km SMF Transceiver
J9153D Aruba 10G SFP+ LC ER 40km SMF Transceiver
JL563B Aruba 10GBASE-T SFP+ RJ-45 30m Cat6A Transceiver
J9152D Aruba 10G SFP+ LC LRM 220m MMF Transceiver
R9X54A Aruba 10G LC BiDi 40km-D 1330/1270 XCVR
R9X55A Aruba 10G LC BiDi 40km-U 1270/1330 XCVR
Table 26: Supported Transceivers
Twisted-pair copper 10 Mbps Operation Category 3, 4 or 5, 100-ohm unshielded twisted-pair
(UTP) or shielded twisted-pair (STP) cable, complying
with IEEE 802.3 10BASE-T specifications.
Table 27: Cabling Specifications
HPE Aruba Networking CX 6200F/M Switch Series Installation and Getting Started Guide |
71
